PLC with Built-In Analog I/O, Relay Output CP1H-XA40DR-A

PLC with Built-In Analog I/O, Relay Output CP1H-XA40DR-A

Original price was: $456.00.Current price is: $91.20.

SKU: SK0038230-US20260630-101428 Category: Tag:

PLC, 100-240 VAC supply, 24 x 24 VDC inputs, 16 x relay outputs 2 A, 4 x analog inputs, 2 x analog outputs, 20K steps program + 32K words data memory

Specifications
Model CP1H-XA40DR-A
S/N: 18414S
Made In CHINA
Condition Surplus New
Other Specifications

Overview:

    Supply voltage type: AC

    Number of digital inputs: 24

    Input type: PNP/NPN

    Number of digital outputs: 16

    Output type: Relay

    Program capacity: 20K steps

    Data memory capacity: 32K words

    Communication ports: USB

    Number of ethernet ports: 0

    Communication options: CAN, CompoNet Master, DeviceNet Master, DeviceNet Slave, EtherCAT Slave, EtherNet/IP, Ethernet TCP/IP, MODBUS Master, MODBUS Slave, PROFIBUS DP Master, PROFIBUS DP Slave, PROFINET Master, Serial RS-232C, Serial RS-422, Serial RS-485

    Number of analog inputs: 4

    Number of analog outputs: 2

    Number of encoder input channels: 4

    Max. encoder input frequency: 100 kHz

    Max. number of PTP axes: 0

    Max. pulse output frequency: 0 kHz

    Max. number of PTP axes: 0

    Max. number of local I/O points: 320

    Max. number of analogue I/O channels: 62

    Max. number of expansion units: 7

    Built-in auxiliary 24 VDC output: 300 mA

    Operating temperature range: 0-55 C
