Pilot-Operated Pressure Reducing Valve PBFB-LAN

Cavity: T-2A

Series: 2

Capacity: 20 gpm

Factory Pressure Settings Established at: Blocked Control Port (dead headed)

Maximum Operating Pressure: 5000 psi

Control Pilot Flow: 0.16-0.25 L/min

Adjustment- No. of CW Turns from Min. to Max. Setting: 5

Valve Hex Size: 1-1/8 in.

Valve Installation Torque: 45-50 lbf ft.

Adjustment Screw Internal Hex Size: 5/32 in.

Locknut Hex Size: 9/16 in.

Locknut Torque: 80-90 lbf in.

Adjustment Range: 100-3000 psi

Control: Standard Screw Adjustment

Seal Material: Buna-N
