Straight Blade Plug, Connection Orientation Straight, Current Rating 15 A, Grounding Grounded, Horsepower Rating 1/2 hp, Housing Color Black, White, IP Rating IP20, NEMA Plug Configuration 5-15P, Number of Blades 3, Number of Poles 2, Phase Single, Polarized Yes, Resistance Properties Corrosion Resistant, UL 94 Flammability Rating HB, Voltage Rating 125V AC, Wire Connection Type Screw Terminals, Wiring Style Standard, For Maximum Cable Diameter 0.72 in, For Minimum Cable Diameter 0.23 in
Item
Straight Blade Plug
Wiring Style
Standard
Grade – Plugs and Receptacles
Hospital
Amps – Plugs and Receptacles
15 A
Voltage – Plugs and Receptacles
125V AC
NEMA Plug Configuration – Plugs and Receptacles
5-15P
Number of Wires
3
Phase – Plugs and Receptacles
1
Antimicrobial
No
Color
Black/White
Number of Poles
2
Phase
Single
Special Features
Corrosion resistant
Voltage
125VAC
Grade
Hospital Grade
HP
0.5
Material
Nylon
IP Rating
IP20
Color – Plugs and Receptacles
Black/White
NEMA Configuration
5-15
Amps
15
Standards
CSA Certified C22.2 No. 42 File 285, Federal Specification W-C-596, UL 498 File E2186
Corrosion Resistant
Yes
Number of Blades
3
Horsepower Rating
1/2 hp
Voltage Rating
125V AC
Resistance Properties
Corrosion Resistant
Grounding
Grounded
Housing Color
Black, White
Wire Connection Type
Screw Terminals
Insulation Material
Nylon
Housing Material Finish
Nickel Plated
Housing Material
Nylon
Current Rating
15 A
NEMA Plug Configuration
5-15P
Connection Orientation
Straight
Power Indicating Lights
Without Power Indicating Lights
Polarized
Yes
Maximum Operating Temperature
75 Degrees C
UL 94 Flammability Rating
HB
Minimum Operating Temperature
-40 Degrees C
Operating Temp.
Maximum continuous 75°C; minimum -40°C (w/o impact)
Body Style
Straight
Flammability
UL 94 HB or better
Dielectric Strength
Withstands 2000V AC minimum
Connector Type
Insulgrip
Weight (Lbs.)
0.15
