Harrington CB080-10 Manual Chain Hoist Hook Mounted – No Trolley, 16,000 lb Lifting Capacity, 10 ft Lift Lg

Manual Chain Hoist, Chain Length 11 ft, For Minimum Beam Flange Width Not Applicable, For Maximum Beam Flange Width Not Applicable, Headroom 30 5/16 in, Includes Brake Brake Included, Lifting Hook Type Hook with Safety Latch, Maximum Lifting Capacity 16,000 lb, Maximum Lifting Length 10 ft, Mount Type Hook Mounted – No Trolley, Body Depth 7 19/32 in, Body Material Steel, Body Width 14 11/16 in, Brake Type Weston Style, Chain Grade Grade 100, Chain Material Manganese Alloy, Color Yellow

Load Capacity	16,000 lb
Hoist Lift	10 ft
Hoist Mount	Hook Mounted – No Trolley
Hoist Overload Protection	Yes
Pull to Lift Rated Load	75 lb
Min. Between Hooks	31 in
Item	Manual Chain Hoist
Trolley Configuration	Hook Mounted – No Trolley
Includes	Slip Clutch
Brake	Weston Style Brake
Standards	ANSI/ASME B30.16, ANSI/ASME HST-2M
Color	Yellow
Features	Bearing-Supported High-Strength Pinion, Double Pawl Springs, High Impact Steel Housing, Maintenance-Free Slip Clutch
Overload Protection Included	Yes
Number of Load Chains	1
Maximum Lifting Capacity	16,000 lb
Resistance Properties	Abrasion Resistant, Corrosion Resistant
Includes Brake	Brake Included
Brake Type	Weston Style
Operating Position	Vertical
Mount Type	Hook Mounted – No Trolley
Chain Grade	Grade 100
Lifting Hook Type	Hook with Safety Latch
Chain Material	Manganese Alloy
Included Components	Safety Latch Hooks
Number of Reeves	3
Includes Clutch	Clutch Included
Body Material	Steel
Power Source	Manual
Lifting Hook Material	Carbon Steel
Headroom	30 5/16 in
