Flange-Mount Ball Bearing Unit – 2-3/16 in Bore, 4-Bolt Flange Mount, Set Screw Locking, Cast Iron Housing Material, Non-Expansion Bearing (Fixed), Intermediate Duty, Contact Seal Seal
Specifications
Model
UCF211-203D1
Condition
Surplus New
Other Specifications
Overview:
Product Type: Flange-Mount Ball Bearing Units
Bore Diameter: 2-3/16 in
Housing Material: Cast Iron
Duty Type: Intermediate Duty
Bolt Center To Center Length: 5.1250 in
Overall Length: 6.3750 in
Bolt Circle Diameter: 5.1250 in
Locking Device: Set Screw
Expansion Type: Non-Expansion Bearing (Fixed)
Seal Type: Contact Seal
Overall Length Diameter: 6.3750 in
Seal Material: Nitrile Rubber
Housing Width: 1.6875 in
Lubrication Type: Relubricatable
Overall Width: 2.2969 in
Bore Type: Straight
Radial Dynamic Load Capacity: 9750 lbf
Radial Static Load Capacity: 6570 lbf
End Type: Open
Length Through Bore: 2-19/64 in
Operating Temperature Range: -40 to 250F
Finish Coating: Uncoated
Standards Met: AFBMA, ISO
Housing Construction: Solid
Type Of Bearing: Ball
Mounting Type: 4-Bolt Flange
