Overload Relay, Auxiliary Contact Form 1NO/1NC, Maximum Overload Relay Current Setting 5 A, Minimum Overload Relay Current Setting 1 A, Trip Class 10/20/30, NEMA Size Not Applicable, Number of Poles 3, Number of Required Thermals Not Applicable, Reset Type Auto, Manual, Includes Thermal Units Not Applicable, Mounting Style Direct To Contactor, Compatible with Series XT Mini Contactors, Frame Size B, Relay Style IEC, Overload Protection Type Electronic, Phase Three
Item – Relay
IEC Style Overload Relay
Current Range
1.00 to 5.00A
Use With – Contactors and Starters
Mfr. Series XTCE Contactors
Overload Relay Current Range
1.00 to 5.00A
Trip Class – Overload
10, 20, 30, 5
Number of Poles
3
Frame / Series / Class / Code
Frame B
Sensing Method
Electronic
Reset Type – Relay
Auto, Manual
Trip Class
10/20/30
Standards
ATEX Compliant, CE, CSA, EN 60947, IEC 60947, RoHS, UL Listed
Separate Mounting
No
For Use With
7 to 15A Contactors
Features
Optional Communications Available, Solid State Overload Relay, Wide Adjustment Range
Starter Type
IEC
Type
Electronic overload relay
Trip type
Selectable 10 A, class 10 ,20, 30
Contact configuration
NO, NC
Overload range
1-5A
Certifications
EN 60947
Mounting method
Direct
Compliances
CE Marked
Product Name
Eaton C440 electronic overload relay
Minimum Overload Relay Current Setting
1 A
Includes Mounting Hardware
Not Applicable
Maximum Overload Relay Current Setting
5 A
Mounting Style
Direct To Contactor
Maximum Operating Temperature
122 Degrees F
Compatible with Series
XT Mini Contactors
Reset Type
Auto, Manual
Number of Required Thermals
Not Applicable
Minimum Operating Temperature
-13 Degrees F
Phase
Three
IP Rating
IP20
Relay Style
IEC
Auxiliary Contact Form
1NO/1NC
Includes Thermal Units
Not Applicable
Overload Protection Type
Electronic
