One-Hole Lug Compression Connector, Barrel Size Standard, Color Code Olive, Die Code 297, Tongue Angle Straight, Tongue Width 1.03 in, For Conductor Material Aluminum, Copper, For Stud Size 1/2 in, For Stranded Copper Wire Size – Minimum 2/0 AWG, For Stranded Copper Wire Size – Maximum 2/0 AWG, Inspection Hole No, Hole Center to Center Not Applicable, Material Aluminum, Maximum Operating Temperature 194 Degrees F, Maximum Voltage 35 kV AC, Termination Style Crimp
Connector Type
Straight Barrel
Material
Aluminum
Color Code
Olive
Plate Material
Electro Tin
Hole Center to End
0.63 in
Die Code
297
Tongue Style
Standard
Standards
CSA Certified, UL 486A-486B, UL Listed
Item
One-Hole Lug Compression Connector
Peep Hole
No
Hole Center to Center
Not Applicable
Maximum Voltage
35 kV AC
For Conductor Material
Aluminum, Copper
For Wire Type
Solid, Stranded
Tongue Thickness
0.2 in
Barrel Style
Chamfered
Tongue Angle
Straight
RoHS Compliant
Yes
Termination Style
Crimp
Special Features
Durable Long Lasting Corrosion Resistance, High-Conductivity, Low Resistance and Ductility, Reliable Connection
Inspection Hole
No
Contact Finish
Tin
Maximum Operating Temperature
194 Degrees F
