12" x 36" Gearhead Metal Lathe w/ Stand No. KC-1236ML/SS-1236

12″ x 36″ Gearhead Metal Lathe w/ Stand No. KC-1236ML/SS-1236

Original price was: $4,311.00.Current price is: $298.98.

SKU: SK0053158-US20260630-101428 Category: Tag:

Specifications
Model KC-1236ML/SS-1236
Made In CHINA
Condition New
General
Horsepower 1.5 hp
Distance Between Centres 36 “
Swing Over Ways 12 “
Swing Over Carriage 7.25 “
Electrical
Voltage 220 volts
Phase Single-phase
Other Specifications
Product Features

    Powerful 1.5 HP motor

    Safety guard with limit switch protection

    Line interruption switch system needs a restart after a power failure

    Guideway and gears in headstock are all hardened and precision ground

    Comes complete with 6″-3 jaw chuck, 8″-4 jaw chuck, imperial and metric gears, quick change tool post, steady rest, follow rest, 10″ DI-4 camlock face plate, thread chasing dial indicator, MT#3 dead center, MT#3 arbor taper, 1/2″ drill chuck, full length splash guard, tool box, chuck keys and hex. keys

Specifications
Distance Between Centers: 36″
Swing Over Bed: 12″
Spindle Bore: 1-1/2″
Swing Over Cross Slide: 7-1/4″
Taper in Headstock: MT #5
Taper in Tailstock: MT #3
Width of Bedways: 7-1/4″
Total Travel of Cross Slide: 6-3/8″
Total Travel of Top Slide: 3-3/8″
Spindle Speeds: 9 (60-1,500) RPM
Thread Cutting Range: 40 (4-112 TPI) 30 (0.2-4.5 mm)
Motor: 8.7 Amp.
Stand Model: SS-1236
