Name: 10 Ton HVAC Rooftop Unit 48TCED08A2G1032823
SKU: SK0038682-US20260630-101428
Availability: InStock

Other Specifications

Accessory Power Exhaust Model: CRPWREXH 022A, 028A

Accessory Power Exhaust FLA: 3.8

Minimum Circuit Amps: 14-18

Max Fuse or HACR Breaker Per NEC: 15-20

Minimum Unit Disconnect: 14-19FLA, 92-96LRA

Down Supply: 0″ – 0mm(Top) 1″ – 25mm(Bottom) 0″ – 0mm(Sides) 48″ – 1219mm(Flue Side)

Side Supply: 0″ – 0mm(Top) 1″ – 25mm(Bottom) 0″ – 0mm(Sides) 48″ – 1219mm(Flue Side)

Air Temp Rise: 35-65 Deg Fahrenheit / 19.4-36.1 Deg Celsius

Max Eternal Static Pressure: 1 in W.C. 0.25kPa

Designed Maximum Outlet Air Temperature: 165 Deg Fahrenheit / 73.9 Deg Celsius

Input Min: 120,000 BTU/HR 35.2KW

Input Max: 180,000 BTU/HR 52.8KW

Output Cap: 148,000 BTU/HR 43.4KW

Therman Efficiency: 82.0%

Equipped For Use With: Natural

Gas Supply Pressure: 13 in W.C. 3.24kPa Max / 4 in W.C. 1 kPa Min

Manifold Pressure: 3.5 in W.C. 0.87 kPa Max / 2 in W.C. 0.5 kPa Min

Cooling: 83,000 Capacity BTU/HR, 24.3 Capacity KW, 11 EER
