1-1/4″ Roller Bearing Pump P2100B131AXHF12-14CHF12-1

Section Type: Multiple (1 additional section)

Gear Width: 1-1/4″

Displacement: 2.50 cu. in.

Flange: 4 bolt SAE B

Shaft Pilot Diameter: 4″

Drive Shaft: 13 tooth spline

Shaft Diameter: 7/8″

1st Section Gear Housing Porting Type: NPT

Left Port: 3/4″ NPT

Right Port: 1″ NPT

2nd Section Gear Housing Porting Type: NPT

Left Port: 3/4″ NPT

Right Port: 1″ NPT

Pump Performance Chart

600 rpm, 4.0 gpm

900 rpm, 7.5 gpm

1000 rpm, 8.5 gpm

1200 rpm, 11.0 gpm

1500 rpm, 14.0 gpm

1800 rpm, 17.5 gpm

2100 rpm, 21.0 gpm

2400 rpm, 24.0 gpm
