1 1/2″ Inlet Air Pilot Control Valve N36491091 3 Way 2 Position

Dimensions

Valve Port Size: 1 1/2 in

Pilot Port Size NPT (In.): 1/4

Length (In.): 5 1/4 in

Port Size (In.): 1-1/2 Inlet, 1-1/2 Exhaust

Height (In.): 7 17/32 in

Width (In.): 6 13/100 in

Overall Width: 6 1/8 in

Overall Height: 5 15/16 in

Pilot Port Connection Size: 1 1/2 in

Overall Length: 5 1/4 in

Valve Port Connection Size: 1 1/2 in

Details

Valve Ways and Positions: 3-Way/2-Position

Valve Actuator / Return: Air Pilot / Air Return

Max. CFM – Valves: 30 cfm

Max. Operating PSI: 140 psi

Type: Normally Closed

Coefficient of Volume: 23.3

Number of Positions: Two-Position

Pilot Pressure: 25 psi

Uses: General Pneumatics Applications

Number of Ways: Three-Way

Max. Temp. Range (F): 0 to 125

Vacuum: External Pilot

Item: Pilot Air Control Valve

Actuator/Return: Air Pilot/Air Return

Valve Type: Poppet

Body Material: Aluminum

Application: Automotive, Foundries, Pulp and Paper Mills, Steel Mills

Standards: CE Certifie

dProduct Type: Pilot Air Control Valve

Operating Temperature – Maximum: 200 Degrees F

For Media: Air

Operating Pressure – Maximum: 250 psi

Body Style: Inline

Actuator Type: Remote Pilot

Coefficient of Volume (Cv): 30

SeriesNFail Position: Open

Lubrication: Lubrication Not Required

Valve Action: Normally Open

Valve Port Connection Type: NPT

Return Action: Pilot Return

Override: No Override

Pilot Port Connection Type: NPT

Operating Temperature – Minimum: 0 Degrees F

Seal Material: Nitrile

Flow Rate – Maximum: 30 scfm
