The 233.34 gauges are for applications with high dynamic pressure pulsations or vibration. Suitable for corrosive environments and gaseous or liquid media that will not obstruct the pressure system. Features a range of 0 to 100 psi.
Specifications
Model
9837787
Condition
Surplus New
General
Gauge Type
Pressure
Filling
Liquid
Pressure Rating
100
Weight + Dimensions
Size
4.5
Thread Size
1/2″ NPT
Other Specifications
Part Number: 9837787
Excellent load-cycle stability and shock resistance
4.5″ diameter dial size
Vacuum / Compound ranges to 400 psi (25 bar); Positive pressure ranges from 15 psi (1 bar) to 30,000 psi (2,000 bar)
Accuracy of -/+0.5% of span;-/+1.0% of span for 20,000 psi (1,600 bar) range and above
Single scales with large figures at beginning and end for quick and easy range identification
Glycerine filled case
Black fiberglass-reinforced thermoplastic (POCAN) case, solid front, blow out back, turret-style case with built in rear flange lugs
Clear acrylic window with Buna-N gasket
1/2″ NPT lower mount process connection
Welded stainless steel safety gauge
All 316SS wetted parts
Weather resistant (NEMA 3/IP54) without membrane; weather tight (NEMA 4X / IP66) filled case with membrane
